Edge Work
Description
Our wide variety of state of the art equipment and knowledgable team are able to polish and edge your unit with a high level of quality. We carry two Bovone flat polishers, a Beveler, a Pencil polisher, a CMS Horizontal CNC, and a CMS Vetical CNC, which allow us to polish nearly any request. Contact your customer service rep here for more details.
Our edge work services include, but are not limited to:
- Flat Polish
- Pencil Polish
- Bevel
- Miter (22.5° or 45°)
- Seamed Edge
- Ogee
.jpg)
Tickness Offered: 1/8" 5/32" 3/16" 1/4" 3/8" 1/2" 3/4"
Straight line Polish:
Flat - 1/8" - 3/4"
Pencil - 5/32" - 1/2"
Miter - 5/32" - 3/4"
Contour Polish:
Flat - 3/16" - 3/4"
Pencil - 3/16" - 1/2"
Ogee - 1/2", 3/4"
| Annealled Beveled | *Glass Thickness | ||||||
| 1/8"-5/32" | 3/16" | 1/4" | 3/8" | 1/2" | 3/4" | ||
| *Bevel Length | 1/2" | Y | Y | Y | Y | Y | Y |
| 3/4" | - | Y | Y | Y | Y | Y | |
| 1" | - | Y | Y | Y | Y | Y | |
| 1 1/4" | - | - | Y | Y | Y | Y | |
| 1 1/2" | - | - | Y | Y | Y | Y | |
*1/2" Annealed Beveled Edge Contour 1/8"-5/32" is not available
|
Temp Beveled |
*Glass Thickness | ||||||
| 1/8"-5/32" | 3/16" | 1/4" | 3/8" | 1/2" | 3/4" | ||
| *Bevel Length | 1/2" | - | - | Y | Y | Y | Y |
| 3/4" | - | - | Y | Y | Y | Y | |
| 1" | - | - | Y | Y | Y | Y | |
| 1 1/4" | - | - | Y | Y | Y | Y | |
| 1 1/2" | - | - | Y | Y | Y | Y | |
Resources
Hole Restrictions
Pattern Requirements
For more information, contact your customer service rep here.
